KFA-500缓冲型圣音马达
KFA-500缓冲型圣音马达参数
| KFA-500 KFB-500 KFH-500 KFK-500缓冲型 | |||||||
| 重量：112kg 长度：60cm | |||||||
| 型号 | 马力 | 级数 | 电压 | 减速比 | 转速RPM | 转出轴径 | |
| MODEL | Kw(HP) | P | VOLTAGE | SPEED RATID | 50HZ | 60HZ | |
| KFA-500 | 3.75KW(5HP) | 4 | 220V-600 | 18.5:1 | 80 | 95 | 50x100 |
| 2.2KW(3HP) | 6 | 53 | 63 | ||||
| 2.2/1.1 KW | 4-8 | 80/40 | 95/47 | ||||
| 2.2/0.75 KW | 4-12 | 80/26 | 95/31 | ||||
| KFB-500 | 3.75KW(5HP) | 4 | 15.3:1 | 93 | 112 | ||
| 2.2KW(3HP) | 6 | 61 | 75 | ||||
| 2.2/1.1 KW | 4-8 | 93/46 | 112/56 | ||||
| 2.2/0.75 KW | 4-12 | 93/30 | 112/37 | ||||
| KFH-500 | 3.75KW(5HP) | 4 | 12:01 | 123 | 148 | ||
| 2.2KW(3HP) | 6 | 82 | 98 | ||||
| 2.2/1.1 KW | 4-8 | 123/61 | 148/74 | ||||
| 2.2/0.75 KW | 4-12 | 123/41 | 148/49 | ||||
| KFK-500 | 3.75KW(5HP) | 4 | 10:01 | 143 | 172 | ||
| 2.2KW(3HP) | 6 | 94 | 116 | ||||
| 2.2/1.1 KW | 4-8 | 143/71 | 172/86 | ||||
| 2.2/0.75 KW | 4-12 | 143/47 | 172/58 | ||||
